Plastic Electrical Box Mould

Plastic Electrical Box Mould – Custom Waterproof Junction Box Injection Mold Manufacturer

ZHONGYUE MOULD is a professional Chinese injection mold manufacturer supplying custom Plastic Electrical Box Moulds / Electrical Junction Box Injection Molds to distributors, OEMs, and electrical enclosure brands worldwide. From compact residential switch boxes to large industrial terminal enclosures and IP65/IP67 waterproof junction boxes, we engineer molds that deliver flash-free parts, precise sealing grooves, and consistent cycle times in ABS, PC, PC+ABS, PP, PVC, and flame-retardant PA66+GF.

Send us your 2D/3D drawings — we provide free DFM analysis and mold flow simulation report before tooling begins.

Plastic Junction Box Mould specifications :

Make your next Plastic Junction Box Mould project brighten!

Applicable Electrical Box Types We Tool

Core Mold Engineering Highlights

Optimized Cooling & Short Cycle Time — Baffle, bubbler, and BeCu inserts placed near thick bosses to reduce warpage and cycle time by 10–20% vs. conventional designs.

Precision Sealing Surface Molding — Cavity finish to SPI A2/B1 polish; sealing groove dimension controlled within ±0.02 mm for reliable IP rating performance.

Flexible Runner & Gating Solutions — Cold runner (sub-gate / edge gate) or branded hot runner (YUDO / HASCO / Mold-Master; open or valve gate) for balanced filling in multi-cavity layouts.

Complex Demolding — Hydraulic Slides / Collapsible Core / Lifters — For side conduit entries, internal threads, undercut knockouts, and snap-fit features.

Recommended Molding Materials & Shrinkage

ABS / HIPS — indoor boxes, shrinkage ~0.4–0.7%; economical & good surface

PC / PC+ABS — outdoor UV-resistant & impact-rated boxes, shrinkage ~0.5–0.7%

PP / Modified PP — low-cost general boxes, shrinkage ~1.2–2.0%

PVC (Rigid uPVC) — corrosion-resistant enclosures, shrinkage ~0.4–0.8%

PA66+GF (25–35%, FR V-0) — industrial high-strength enclosures, shrinkage ~0.2–0.5%

Frequently Asked Questions

Q: Can you make molds for both the box body and the cover/lid?

A: Yes. We commonly design matched mold sets — one for the junction box body (often with side cores/slides) and one for the cover/lid (often simpler, sometimes family mold if size permits).

Q: What is the minimum order and lead time?

A: MOQ is 1 set. Standard lead time is 35–55 days after final 3D design confirmation. Rush service is available for certain structures.

Q: Do you provide mold trial samples and inspection reports?

A: Yes. We run T1/T2 trials on our in-house injection machines, and supply trial video, dimensional CMM report, and samples for your approval before shipment.

Q: Which countries do you export to?

A: ZHONGYUE MOULD has exported molds to Europe (Germany, Italy, UK), North America (USA, Canada), South America, the Middle East, and Southeast Asia.

Why Partner with ZHONGYUE MOULD?

Specialist in Electrical & Enclosure Molds — 15+ years focused experience in junction box, switch box & distribution box tooling

Free DFM & Mold Flow Report — Identify potential issues before steel cutting

Strict In-process QC — Weekly progress photos, final CMM inspection, T1 sample approval

Export-ready Packaging & Documentation — Fumigation-free case, steel certs, heat treatment cert, operation manual

1-Year Mold Warranty + Spare Parts — Lifetime technical support

Get a Quote for Your Plastic Electrical Box Mould

Email your part drawings (STEP/IGS/STP/DWG/PDF) with:

Annual production volume / required cavitation

Target plastic material

Special requirements (IP rating, texture, hot runner brand preference)

ZHONGYUE MOULD will respond with DFM feedback and formal quotation within 24 working hours.
