ZHONGYUE MOULD is a professional Chinese injection mold manufacturer supplying 40L Storage Box Moulds / 40 Liter Household Storage Container Injection Molds (Medium-Capacity Rectangular Organization Crates, Closet/Office/Workshop Storage Boxes) to global household-products wholesalers, supermarkets, and private-label brands. The 40L storage box is a versatile mid-to-large home/warehouse organizer — most commonly molded in PP (Polypropylene, MFR 8–15 g/10min, optionally with UV stabilizer & color MB) with a smooth or light VDI 27–30 outer surface (SPI B1/B2 satin inner face) for easy cleaning and attractive appearance. Our 40L box molds feature dual isolated water circuits with central baffle Ø10–12mm + BeCu (Beryllium Copper) insert at bottom corner radii, hidden submarine gate on the top flange or inner rim (no visible gate vestige), DFM-verified wall thickness (2.0–3.0mm), and a single-cavity (1×1) layout with optional 2-cavity or 4-cavity matching lid mold for balanced daily output. Carry-handle recess (if present) is handled via a small loose insert or mini angled slide (H13 nitrided).

From 40L rectangular stackable storage boxes (with/without side carry-handle recess), matching snap-fit or hinge lids (opaque/clear), to inner divider trays (optional separate mold), we provide full DFM review and Moldflow cooling/fill analysis before steel cutting.

Plastic Injection Storage Box Mould specifications :

Make your next Plastic Storage Box Mould project brighten!

What Is a Plastic Storage Box Mold & How Does It Work? (40L Context)

A Plastic Storage Box Mold is a precision cavity-and-core tool mounted in an injection molding machine. For a 40L box (~500×350×300mm, draw depth 280–320mm), the mold consists of a hollow cavity (shaping outer walls, stacking lips, handle recess) and a long core (forming inner volume). PP resin is heated to ~180–230℃, injected under high pressure into the closed mold, fills every corner — including handle recess & stacking ledges — then cools for 22–35s cycle (typical for 40L PP box, shot weight ≈2.0–2.8kg). After solidification, the mold opens and the finished 40L storage box is ejected.

A well-built 40L storage box mold from ZHONGYUE MOULD delivers ≥300,000 shots (P20) or ≥500,000–1,000,000 shots (718H/2738HH) with consistent wall thickness, sharp corner definition, and clean parting-line finish — suitable for home, office, light industrial use.

Key Engineering Features of a Durable 40L Storage Box Mold

A 40L box mold runs on 500T–1000T injection machines and must endure higher clamp force & thermal cycling than 10L/20L tools. Our molds include:

High-Grade Mold Steel — Cavity & Core in P20 (pre-hard HRC 28–33) standard; upgradeable to 718H (HRC 33–38) or 2738HH for longer life & better polish/texture retention.

Precision-Machined Cavity Dimensions — PP shrinkage ~1.2–1.8% compensated; box L/W ±0.2mm, stacking lip flatness ±0.3mm, ensuring perfect lid-seat & stackability across batches.

Dual Isolated Cooling Circuits + BeCu Corner Insert — Ø10–12mm central baffle through core + BeCu (MOLDMAX™/Ampcoloy) insert at bottom corner radii where wall thickens; 2 isolated water circuits (cavity side & core side) keep ΔT ≤3–4℃ inlet–outlet, reducing cycle & warp on deeper 280–320mm draw.

Smooth Inner Surface & Controlled Outer Texture — Core polished SPI B1/B2 (easy-release, smooth box interior); Cavity SPI B1 satin standard or light VDI 27–30 leather grain on request — NO rattan/woven EDM etching unless specially ordered.

Mini Slide / Loose Insert for Carry Handle Recess (if any) — H13 (2344 ESR) nitrided insert or shallow angled slide (stroke 5–15mm) for side-handle undercut; interference checked in 3D assembly.

Deep-Core Venting — 0.01–0.015mm parting-line vents + vent pins / porous steel vent at last-fill zone (core top/shoulder) — critical on 280–320mm draw PP boxes to prevent burn/short-shot.

Applications Across Markets

Why Choose ZHONGYUE MOULD for Your 40L Storage Box Mold?

Selecting your injection mold partner is critical. ZHONGYUE MOULD has 15+ years' experience in household commodity molds — storage boxes (5L–120L), crates, chairs, dust bins, rattan baskets — with in-house CAD/CAM/CAE (UG NX, Pro/E, SolidWorks, Moldflow), full-size CNC & EDM, and export track record to Europe, North & South America, Southeast Asia, Middle East.

We don't just "make a mold" — we review your part drawing, run DFM & Moldflow cooling/warp analysis, suggest wall-thickness / gate / ejection / handle-undercut improvements, and only proceed to steel cutting after your sign-off. Each mold ships with T1 trial video, sample parts + CMM report, operation manual & spare-parts list.

Our 40L Storage Box Molding Procedure at ZHONGYUE MOULD

3D Product & Mold Design (DFM Stage) — Receive your 2D/3D (STP/IGS/X_T); analyze wall thickness (2.0–3.0mm), draft angle (≥1.5° smooth / +0.5° if light grain), gate location (submarine on top inner flange), cooling layout (dual circuits + BeCu spec.), carry-handle recess (mini-insert or slide), and lid-match clearance. Provide free DFM report & improvement suggestions.

Material & Steel Confirmation — P20 (std.) or 718H/2738HH per volume; mold base LKM/DME/HASCO; hot runner (YUDO/SYNVENTIVE 1-tip open) or cold sub-gate per preference.

Precision Machining — High-speed CNC rough/finish cavity & core, deep-hole drilling for cooling baffle, H13 mini-insert nitriding & hand-fit, BeCu insert installation & thermal-contact check, SPI B1/B2 polish or VDI light etch.

Assembly, T1 Trial & Correction — Run on in-house machine, check ovality/flatness, wall thickness scan, lid-seat fit (if lid sample available), supply trial video + samples + dimensional report. Fine-tune if needed.

Final Packaging & Shipment — Fumigation-free heavy-duty wooden case; mold manual; spare parts (ejector pins, water nozzles, sprue bushing, mini-insert if applicable); steel certs & heat-treatment docs.

After-Sales Support — 1-Year warranty (non-man-made damage), free spare parts, remote technical guidance for re-cutting vents / adjusting ejection.

Frequently Asked Questions — 40L Storage Box Mold

Q: How is the 40L box mold different from 10L or 50L?

A: 40L is a mid-capacity box — deeper draw (~280–320mm) than 10L (180–250mm) → needs dual cooling circuits + BeCu corner insert and typically runs on 500T–1000T machines vs. 350T–650T for 10L. Shot weight ≈2.0–2.8kg PP (vs. ~0.7–1.2kg for 10L, ~2.8–3.5kg for 50L). 50L mold is heavier, sometimes with thicker reinforcement & larger base. All are 1×1 cavity standard; lid mold cavity count matched to body cycle.

Q: Do you also make the matching lid mold?

A: Yes. We quote the 40L box body as 1×1 cavity and the lid as 2-cavity or 4-cavity mold (shorter cycle ~10–18s) to balance daily output. Lid can be PP (opaque/colored), clear PS, or ABS (premium) — separate quote.

Q: What steel do you recommend for 300k–500k shot program?

A: P20 (HRC 28–33) is cost-effective for 300k+ shots. For 500k–1M shots or better surface retention with light VDI grain, we recommend 718H (HRC 33–38) or 2738HH.

Q: Submarine gate or hot runner?

A: Default is cold sub-gate on inner top flange (hidden vestige, auto-degating) — simple & reliable. Hot runner (YUDO/SYNVENTIVE 1-tip open) is optional for high-volume runs to eliminate runner scrap.

Q: Can you add a carry-handle recess / undercut?

A: Yes — designed via a loose changeable insert or mini shallow slide (H13 nitrided). DFM checks interference & draft. Handle itself is NOT molded — bought-in plastic/metal assembled post-molding.

Q: What do you need for a quotation?

A: 2D drawing (PDF/DWG) + 3D model (STP/IGS/X_T) OR clear photos with dimensions (L×W×H, wall thickness, weight, capacity), annual volume, preferred cavity count for lid (2×1 etc.), material (PP MFR / UV yes/no). If you also want lid mold, please share lid sketch/dimensions or confirm "same perimeter as body top".
