ZHONGYUE MOULD is a professional Chinese injection mold manufacturer supplying Plastic Scalloped Large Size Flower Pot Moulds / Petal Edge Fluted Rim Planter Molds (Ornamental Scalloped Pots, Wavy Rim Planters, Lotus-Style Garden Urns) to global high-end landscape contractors, five-star hotel procurement, and luxury garden decor brands. Unlike standard round pots, these Scalloped Large Pots feature a decorative, undulating rim (like flower petals or ocean waves) that repeats around the circumference, creating a classic, ornate appearance. Sizes typically range from 300mm to 800mm in diameter.
Molding these requires overcoming significant tooling challenges: the scalloped edge creates undercuts that prevent simple stripping off a core, and the large top flange is prone to warpage. Our molds utilize multiple angle lifters (8–16 lifters) or a collapsible core mechanism to withdraw the scalloped profile, combined with massive BeCu cooling inserts to control flatness on the wide rim. We produce these in virgin PP (UV-stabilized), Fiberglass Reinforced PP (FRPP), or Premium ABS to ensure the large structure remains rigid and weather-resistant.
From classic Victorian-style scalloped urn planters to modern wavy-rim architectural pots, we provide full DFM review focusing on lifter synchronization and flange flatness before steel cutting.
|
Item |
Specification / Options |
|
|
Mold Name |
Plastic Scalloped Large Size Flower Pot Mould (Petal Edge / Fluted Rim Planter) |
|
|
Cavity & Core Steel |
Cavity: 718H (HRC 33–38) or 2738HH (stability). Core: 718H.Lifters: H13 (2344 ESR, Nitrided HRC 48–52) |
|
|
Mold Type |
Two-plate mold withMultiple Angle Lifters (8–16) orCollapsible Core |
|
|
Mold Base |
LKM / DME Heavy-Duty (Weight 3.0T – 10.0T depending on size) |
|
|
Cavities |
1×1 standard (Complexity prohibits multi-cavity for large scalloped pots) |
|
|
Runner System |
Cold runner (Y-branch to multi-gates) orHot Runner (Sequential Valve Gate) to control fill in large volume |
|
|
Gate Type |
Fan gate or Edge gate at the base of the rim or inner flange |
|
|
Ejection |
Ejector pins + Ejector sleeves (for deep cores) +Synchronized Lifter Actuation Plate |
|
|
Cooling |
BeCu inserts in rim area + Baffles in core + Peripheral bubblers; Isolated circuits |
|
|
Surface Finish |
Cavity:VDI 27–30 Leather Grain or Stone Texture; Core: SPI B1/B2 Polish |
|
|
Mold Life Expectancy |
≥300,000 shots (718H + H13 lifters); ≥500,000 shots (full hardened) |
|
|
Recommended Material |
UV-Stabilized PP, Fiberglass Reinforced PP (FRPP), Premium ABS |
|
|
Design Software |
UG NX, SolidWorks, Moldflow (Fill + Pack + Warpage + Lifter Motion) |
|
|
Tolerance Control |
±0.2 mm general; Scallop pitch repeatability ±0.1mm; Rim flatness ≤0.5mm |
|
|
Lead Time |
60–85 days (Complex lifter machining & fitting) |
|
|
Mould material |
Hardness |
Mould life |
|
P20 |
HRC 28-33 |
>300,000 shots |
|
718 |
HRC 33-36 |
>500,000 shots |
|
H13 |
HRC >43 |
>800,000 shots |
|
2344 |
HRC >48 |
>800,000 shots |
|
S136 |
HRC 48-52 |
>1,000,000 shots |
Make your next plastic Flower Pot Mould project brighten!
A Scalloped Large Size Flower Pot Mould is a complex tool designed to create large planters with a repeating decorative edge:
Scalloped / Petal Edge — The top rim is not flat; it has periodic convex (petals) and concave (valleys) curves. This creates negative draft that requires mechanical withdrawal.
Large Diameter — Typically 300mm–800mm. The large surface area demands exceptional cooling and warpage control.
Deep Draw — Often tall pots (300mm–600mm height), requiring deep core cooling and robust ejection.
Ornamental Finish — Usually features a light leather grain (VDI 27–30) or stone texture over the entire outer surface, including the scallops.
This is the heart of the mold. We design 8 to 16 individual angle lifters arranged in a circle, each forming one scallop. Alternatively, for tighter pitches, we use a collapsible core (segmented core with central cam). All lifters move simultaneously via a single actuation plate to ensure synchronized retraction without distorting the delicate rim.
The wide, flat top rim is prone to cupping or twisting. We design internal cooling channels (baffles or BeCu inserts) within 5mm of the surface and use Moldflow analysis to optimize packing pressure and cooling time, guaranteeing flatness ≤0.5mm on rims up to 800mm wide.
Every scallop must be identical. We use high-precision CNC machining and hand-fitting of the lifters to ensure the transition between each petal is seamless and the pitch (number of scallops) is consistent around the circumference.
The outward force exerted by 8+ lifters during injection is immense. We use thick support pillars, high-tensile guide pins, and heavy-duty lifter shoes to prevent mold deflection and flash.
Deep cores are cooled with BeCu bubbler tubes or spiral baffles. Deep venting (0.01–0.015mm) is placed at the apex of each scallop valley to prevent air traps in the complex geometry.
The scalloped surface often carries a stone or leather texture. We ensure the texture is applied uniformly across the lifter faces and the cavity, with proper draft (2.5–3.5°) to allow release from the textured undercut.
|
Market Segment |
Application & Mold Requirement |
|
Luxury Real Estate & HOAs |
Large 600–800mm urn planters lining driveways; FRPP for strength; classic scalloped edge |
|
Five-Star Hotels & Resorts |
Decorative poolside or entrance planters; Premium ABS with high-gloss or faux-stone finish |
|
Municipal & Botanical Gardens |
Public space landscaping; UV-stabilized PP; robust design to withstand public interaction |
|
Historic Restoration Projects |
Replicating Victorian or Classical architectural planters; precise scallop geometry |
Lifter Motion & Warpage DFM — Analyze scallop depth and draft. Simulate lifter movement to ensure no collision. Run Moldflow to predict rim warpage and cooling efficiency. Free DFM report.
Hardened Steel Machining — CNC roughing of complex cavity. Gun-drilling of BeCu cooling channels in the rim area.
Lifter & Core Fitting — Grind H13 lifters to micron tolerance. Nitride surface. Hand-fit lifters to cavity to ensure seamless texture transition across the parting line.
Assembly & T1 Trial — Assemble synchronized lifter plate. Run T1 trial with specified material. Check for scallop definition, rim flatness, and complete lifter retraction. Supply trial video + samples + CMM report.
Final Delivery — Heavy-duty packaging. Provide lifter maintenance schedule and hydraulic schematics (if applicable). Spare parts for lifters (springs, guide shoes).
Scalloped Edge Specialists — We have mastered the complex mechanics of multi-lifter and collapsible core systems for decorative rims.
Warpage Control Experts — We solve the #1 problem of large planters: flat, stable rims that don't twist or cup.
Robust Tool Construction — Our molds are built like tanks to withstand the enormous side forces generated by scalloped undercuts.
Texture Integration — Applying leather/stone texture to a scalloped surface requires expertise in draft and polishing, which we provide.
Global Experience — Molds delivered to European landscape contractors and North American hotel chains.
Q: Why does this mold need so many lifters?
A: Each "petal" or "scallop" creates an undercut. A standard mold cannot eject this. We need one lifter (or a segment of a collapsible core) for every scallop to pull the steel away from the plastic.
Q: Can you make multi-cavity molds for these?
A: For large diameters (over 300mm), multi-cavity is extremely rare due to the complexity of the lifter systems and the massive mold base required. We almost always recommend 1×1.
Q: What material do you recommend for a 600mm scalloped pot?
A: For rigidity and to prevent the wide rim from warping, we recommend Fiberglass Reinforced PP (FRPP) or Premium ABS. Standard PP may be too flexible for such a large size.
Q: How do you ensure the rim is flat?
A: We use BeCu cooling inserts right at the rim surface to extract heat evenly and quickly, combined with optimized packing pressure based on Moldflow analysis.
Q: What do you need for a quotation?
A: A 3D model (STP/IGS) is mandatory. Please specify the material (PP/ABS/FRPP), desired texture (e.g., "light leather grain"), and annual volume.
Send your Scalloped Pot 3D model (STP/IGS) and project requirements to ZHONGYUE MOULD. We will provide a free DFM report covering lifter strategy, warpage control, and cooling design + formal quotation within 48 working hours.
Contact us now to start your Petal Edge / Fluted Rim Planter Injection Mold project!
